DLE170 model airplane engine

Stock:

0

€ 1049.00

Current combination not in stock.

• Back

| More

• Description
• Images and videos

DLE170 2 stroke model airplane engine

Performance:
17.5HP/9000rpm
Idle Speed: 1100 rpm/min
Static Thrust 35Kg / 100 meters Altitude
Static Thrust 31.5Kg / 1800 meters Altitude
The specification of the aircraft propeller: 30 X 12; 32 X 10
the type of the sparking plugFNGK CM6

Parameter:
Exhaust Amount: 170cm3
diameter × stroke: 52mm×40mm
Ratio of compression: 9.5F1
Ratio of lubricating capacity: 30:1
Weight: Main engine - 3550g Exhaust pipe - 200g X 2
Ignition equipment - 160g

www.dlpower.net/uploadfile/20101004224507737.pdf
